Specifications
| Brand | Schneider Acti9 |
| Manufacturer part no. | A9DE3625 |
| current rating | 25A |
| depth | 73mm |
| dimensions | (H)85 mm x (W)36 mm x (D)73 mm |
| guarantee | 1 Year |
| height | 85mm |
| incoming terminal capacity | 16mm² |
| mounting | DIN Rail |
| number of modules | 2 |
| number of poles | Single Pole and Neutral |
| packaging types | Each |
| product range | Acti9 |
| rcd type | AC |
| short circuit rating | 6kA |
| standards | IEC/EN 61009-2-1 |
| tripping characteristics | C Curve |
| tripping sensitivity | 30mA |
| unspsc v18 | 39121601 |
| unspsc v24 | 39121601 |
| voltage rating | 230V |
| weight | 0.21200kg |
| width | 36mm |
