Specifications
| Brand | Sangamo |
| Manufacturer part no. | CHPPR3 |
| battery back up | Yes |
| battery size | CR1225 |
| battery type | Lithium |
| boost | 1, 2 or 3 hrs |
| colour | White |
| compliance | CE |
| current rating | 2A |
| current rating inductive | 1A |
| depth | 32.1mm |
| dimensions | (H)88.6 mm x (W)140 mm x (D)32.1 mm |
| finish | White |
| gravity fully pumped | Fully Pumped |
| guarantee | 3 Years |
| height | 88.6mm |
| holiday setting | Yes |
| industry standard backplate | Yes |
| ip rating | IP30 |
| manual override | Yes |
| material | Thermoplastic |
| maximum operating temperature | 40°C |
| minimum operating temperature | 0°C |
| mounting | Wall |
| number of channels | 3 |
| number of on offs | 3 |
| packaging types | Each |
| product range | Choice |
| programming type | 24 Hour, 5/2 & 7 Day |
| standards | EN 60730-1, EN 60730-2-7, EMC Directive 2004/108/EC, LVD Directive 2006/95/EC |
| unspsc v18 | 39121523 |
| unspsc v24 | 39121523 |
| voltage free contacts | Yes |
| voltage rating | 230V |
| weight | 0.32kg |
| width | 140mm |
