Specifications
| Brand | Rolec EV |
| Manufacturer part no. | ROLEC0323B |
| charging access | Free to Use / App / RFID |
| charging mode | 3 |
| charging power | 22kW |
| colour | Black |
| compliance | Manufactured in Compliance with BS7671 Wiring Regulations |
| connectivity | 4G Bluetooth Ethernet Wi-Fi |
| current rating | 32A |
| depth | 155mm |
| dimensions | (H)575 mm x (W)320 mm x (D)155 mm |
| dynamic load managemen | Yes |
| ev type | IEC 62196 (Type 2) |
| frequency | 50/60 Hz |
| guarantee | 3 Years |
| height | 575mm |
| ik rating | IK10 |
| ip rating | IP54 |
| kw rating | 22kW |
| lockable | Yes |
| material | Heavy Duty, Vandal Resistant Steel |
| metered | Yes |
| mounting | Wall / Pedestal |
| number of chargepoints | 2 |
| number of ways | 2 |
| ocpp compliant | OCPP 1.6 |
| off peak charging | Yes |
| operating temperature range | -30 - 50°C |
| output type | 2 x Type 2 Sockets |
| ozev approval | WCS |
| packaging types | Each |
| pen fault protection | Yes |
| product range | SecuriCharge Intelligent |
| socket protection | Built-in 30mA Type A RCBO and 6mA DC Sensitive Device |
| status indicator | LED |
| suitable for | Public / Workplace |
| type | Mode 3 |
| unspsc v18 | 25175002 |
| unspsc v24 | 25175002 |
| voltage rating | 415V |
| weight | 18.00000kg |
| width | 320mm |
