Specifications
| Brand | Proteus |
| Manufacturer part no. | SF40 |
| cable entry | Knockouts 2 x 20mm and 2 x 25mm |
| current rating | 40A |
| depth | 90mm |
| dimensions | (H)225 mm x (W)114 mm x (D)90 mm |
| door type | Top Hinged |
| guarantee | 1 Year |
| height | 225mm |
| incoming terminal capacity | 50mm² |
| ip rating | IP30 |
| material | Polyester Powder Coated Steel Construction |
| mounting | Surface |
| number of poles | Single Pole and Neutral |
| outgoing terminal capacity | 50mm² |
| packaging types | Each |
| product range | Single Phase Switch Fuses |
| short circuit rating | 16kA |
| standards | BS EN 61947 parts 1&3, BS 88 pt 2 |
| supplied with | HRC Fuse |
| type | Single Phase Switch Fuses |
| unspsc v18 | 39121116 |
| unspsc v24 | 39121116 |
| utilisation category | AC22B |
| voltage rating | 230V 400V |
| weight | 1.44900kg |
| width | 114mm |
