Specifications
| Brand | Megger |
| Manufacturer part no. | MFT-X1-EVCA210 KIT |
| 3 phase rotation | Yes |
| ac voltage measurement | 600V AC |
| batteries included | Yes |
| battery level indicator | Yes |
| battery type | Lithium-Ion |
| continuity check | Yes |
| continuity range | 0.01 Ω - 999 kΩ |
| dc voltage measurement | 1000V DC |
| depth | 143mm |
| dimensions | (L)274 mm x (W)96 mm x (D)143 mm |
| display type | LCD |
| earth electrode test | Yes |
| guarantee | 3 Years |
| insulation resistance measuring range | 0.01 MΩ - 999 MΩ |
| insulation test voltage | 50V / 100V / 250V / 500V / 1000V |
| ip rating | IP54 |
| length | 274mm |
| loop impedance range | 0.01 Ω - 1000 Ω |
| number of batteries | 1 |
| packaging types | Each |
| rcd settings | ½ / x1 / x5 @ 0° and 180° / Type AC / A / B / S / Auto and Ramp Tests |
| rcd test range | 10 mA / 30 mA / 100 mA / 300 mA / 500 mA / 1000 mA |
| rechargeable | Yes |
| safety range | CAT III 600V, CAT IV 300V |
| standards | IEC 61010, IEC 61557, EMC IEC 61326 |
| supplied with | MFT-X1 Multifunction Tester, Switched Test Probe,Test Leads with Probes and Grabbers, Li-ION Battery, Charger, Mains Socket Interface Adaptor, EVCA210 EV Test Kit, Neck strap, Multipurpose Hard Base Carry Case, Quick Start Guide and Calibration Certificate |
| type | Multifunction Installation Tester |
| unspsc v18 | 41113681 |
| unspsc v24 | 41113681 |
| weight | 3.30000kg |
| width | 96mm |
