Specifications
| Brand | MCG |
| Manufacturer part no. | 40A2P100ATD |
| bidirectional | Yes |
| compliance | UKCA, CE |
| current rating | 40A |
| depth | 65mm |
| dimensions | (H)82.5 mm x (W)36 mm x (D)65 mm |
| guarantee | 1 Year |
| height | 82.5mm |
| incoming terminal capacity | 35mm² |
| material | Plastic |
| mounting | DIN Rail |
| number of modules | 2 |
| number of poles | 2 Pole |
| outgoing terminal capacity | 35mm² |
| packaging types | Box |
| rcd type | A |
| short circuit rating | 6kA |
| standards | IEC 61008-1 |
| time delay | Yes [200 - 300ms] |
| torque settings | 2.5Nm |
| tripping sensitivity | 100mA |
| type | Type A |
| unspsc v18 | 39121614 |
| unspsc v24 | 39121614 |
| voltage rating | 230V |
| weight | 0.18600kg |
| width | 36mm |
