Specifications
| Brand | MCG |
| Manufacturer part no. | 10A1PB10 |
| bidirectional | Yes |
| compliance | UKCA, CE |
| current rating | 10A |
| depth | 66mm |
| dimensions | (H)82.5 mm x (W)18 mm x (D)66 mm |
| guarantee | 1 Year |
| height | 82.5mm |
| incoming terminal capacity | 25mm² |
| material | Plastic / Metal |
| mounting | DIN Rail |
| number of modules | 1 |
| number of poles | Single Pole |
| operating temperature range | -25 - 40°C |
| outgoing terminal capacity | 25mm² |
| packaging types | Each |
| short circuit rating | 10kA |
| standards | IEC/EN 60898-1 |
| tripping characteristics | B Curve |
| unspsc v18 | 39121603 |
| unspsc v24 | 39121603 |
| voltage rating | 230V |
| weight | 0.11200kg |
| width | 18mm |
