Specifications
| Brand | ICS |
| Manufacturer part no. | ICS22ET |
| cable length | 5m |
| charging access | Push Button / Auto Start/ App / RFID |
| charging mode | 3 |
| charging power | 22kW |
| colour | Black |
| compliance | CE, UKCA |
| connectivity | 4G Bluetooth Ethernet Wi-Fi |
| current rating | 32A |
| depth | 128mm |
| dimensions | (H)288 mm x (W)208 mm x (D)128 mm |
| dynamic load managemen | Yes |
| ev type | Type 2 |
| finish | Black |
| frequency | 50/60 Hz |
| guarantee | 5 Years |
| height | 288mm |
| ik rating | IK08 |
| ip rating | IP55 |
| kw rating | 22kW |
| metered | Yes |
| mounting | Wall / Pedestal [Sold Separately] |
| number of chargepoints | 1 |
| number of ways | 1 |
| ocpp compliant | OCPP 1.6 |
| off peak charging | Yes |
| operating temperature range | 30 - 50°C |
| output type | Type 2 Tethered Lead |
| ozev approval | EVHS / WCS |
| packaging types | Each |
| pen fault protection | Yes |
| product range | E Series - ISO15118 AC Chargers |
| socket protection | Overload, DC Sensitive and Fault Current Protected |
| standards | CE, UKCA, EN61851-1, EN61851-21-2, EN61000-3-11, EN6100-3-12 |
| status indicator | LED |
| suitable for | Home and Light Commercial |
| type | Mode 3 |
| unspsc v18 | 25175002 |
| unspsc v24 | 25175002 |
| voltage rating | 415V |
| weight | 6.20010kg |
| width | 208mm |
