Specifications
| Brand | Ethos |
| Manufacturer part no. | ETHOS 8400 |
| 3 phase rotation | Yes |
| ac voltage measurement | 440V AC |
| batteries included | Yes |
| battery level indicator | Yes |
| battery size | AA |
| battery type | Alkaline |
| continuity check | Yes |
| continuity range | 0.01 Ω - 19.99 kΩ |
| depth | 140mm |
| dimensions | (H)115 mm x (W)245 mm x (D)140 mm |
| display type | LCD |
| guarantee | 3 Years |
| height | 115mm |
| insulation resistance measuring range | 250V 0.001 MΩ - 200.0 MΩ / 500V 0.001 MΩ - 500.0 MΩ / 1000V 0.001 MΩ - 1000 MΩ |
| insulation test voltage | 250V / 500V / 1000V |
| ip rating | IP54 |
| kit contents | 1 x 3 Wire Lead Set with Prods and Clips, 1 x Switched Probe, 1 x Mains Plug Test Lead, 1 x AC Battery Charger, 1 x Neck Strap, 1 x Calibration Certificate and 1 x Large Soft Pouch |
| loop impedance range | Hi Current 0.000 Ω - 500.0 Ω / No Trip 0.00 Ω - 500.0 Ω |
| number of batteries | 6 |
| packaging types | Each |
| product range | Multifunction Testers |
| rcd settings | ½ / x1 / x5 @ 0° and 180° / Auto and Ramp Tests |
| rcd test range | 30 mA / 100 mA / 300 mA / 500 mA |
| safety range | CAT III 600V, CAT IV 300V |
| standards | IEC 61010, IEC 61557, EMC IEC 61326 |
| supplied with | 1 x 3 Wire Lead Set with Probes and Croc Clips 1 x Switched Probe 1 x Mains Plug Test Lead 1 x Calibration Certificate 6 x AA Batteries 1 x Heavy-Duty Carry Case |
| type | Multifunction Installation Tester |
| unspsc v18 | 41113681 |
| unspsc v24 | 41113681 |
| weight | 1.50000kg |
| width | 245mm |
